Katool ME-LM1100 Single Lock Release Two Post Vehicle Lift 11,000lbs

The Katool ME-LM1100 is a professional-grade 11,000 lb two-post lift engineered for serious automotive work. It pairs CE-certified safety, a single-point lock release, and a symmetric clear-floor design to deliver reliable performance for working shops and dedicated home garages. A 94.5" drive-through clearance gives easy undercarriage access for routine service, repairs, and inspections.

Key Features

• 11,000 lbs Capacity: Lifts full-size trucks, SUVs, and heavy passenger vehicles.
• Clear-Floor Design: Symmetric arms with no crossbeam underfoot — full undercarriage access.
• Single-Point Lock Release: One control point for safe, repeatable lock disengagement.
• CE Certified: Manufactured to European safety and quality standards.
• Dual Hydraulic Cylinders: Chain-drive system delivers smooth, balanced rises.
• 94.5" Drive-Through: Wide clearance for comfortable underbody work.

Safety Features

• Overhead Shutoff Bar: Auto-stop prevents over-travel into the ceiling.
• Multiple Safety Locks: Mechanical locks engage at multiple heights.
• Single-Point Lock Release: Controlled, safe lowering mechanism.
• Rubber Door Guards: Cushion vehicle doors during entry and exit.
• Feet Protection Rails: Base barriers protect installer feet around the columns.
• Automatic Arm Restraints: Lift arms stay locked in position during operation.

Perfect For

• Professional Auto Repair Shops: Daily heavy-duty use.
• Serious Home Mechanics: Garages that meet ceiling and electrical specs.
• Full-Size Vehicles: Trucks and SUVs up to 11,000 lbs.
• Undercarriage Work: Exhaust, transmission, and suspension repairs.
• Brake & Tire Service: Full wheel access with the vehicle elevated.

Electrical Requirements

• Voltage: 220V AC (not a standard 110V outlet).
• Installation: Hardwired connection required.
• Circuit: Dedicated 20–30 amp circuit recommended.
• Electrician: Licensed professional installation required.
• Permit: Electrical permit may be required in your area.

Installation Process

• Step 1: Verify garage meets all requirements (ceiling, floor, electrical).
• Step 2: Mark anchor bolt positions per manual specifications.
• Step 3: Drill holes and install anchor bolts into concrete.
• Step 4: Assemble columns and overhead beam (2–3 people recommended).
• Step 5: Install hydraulic system and connect power unit.
• Step 6: Have a licensed electrician hardwire 220V power.
• Step 7: Test all safety systems before first vehicle lift.
• Professional Install Time: 4–6 hours for an experienced team.

Common Service Tasks

• Oil changes and fluid service
• Exhaust system repairs and upgrades
• Transmission service and repairs
• Suspension work (shocks, struts, control arms)
• Brake service (rotors, calipers, lines)
• Differential and driveline repairs
• Undercarriage rust treatment and inspection
• Frame and subframe repairs

Maintenance Schedule

• Daily: Visual inspection before each use.
• Weekly: Check safety locks, arm restraints, and lift pads.
• Monthly: Inspect hydraulic fluid and check for leaks.
• Quarterly: Lubricate moving parts per manual.
• Annually: Professional inspection and certification.
• As needed: Replace worn pads, check anchor bolt torque.
